Recently, an Emirati client ordered two sets of pneumatic hoists from us. This client is our agent distributor in the United Arab Emirates. Our agent has a client who needs to buy a pneumatic hoist. Through deep communication, we know the client's actual applications, and then we recommend that they buy two sets fixed type pneumatic hoists. Besides the fixed type air hoists, we can also supply you with trolley type pneumatic hoists. Therefore, we suggest a suitable machine according to your needs. We have lots of agent distributors in many countries all over the world. And, if you have some customers who want to buy hoists, we welcome you to be our agent. We look forward to establishing a long-term business relationship with you. We are a professional manufacturer of pneumatic hoists in China. Our air hoists have been sold to lots of countries around the world. If you have a plan to order an air hoist, please feel free to contact us! For more details about this order, please keep reading!
| Item | Fixed Type Pneumatic Hoist |
| Lifting capacity | 10t |
| Lifting height | 10m |
| Number of chains | 1 |
| Rated Load Up | 1.6 m/min |
| No Load Up | 3.2 m/min |
| Rated Load Down | 3.4 m/min |
| Rated Load Upair Consumption | 4 m²/min |
| Consumption | 5.5 m²/min |
| Air Pressure | 0.6 Mpa |
| Chain Size | 16*45 mm |
| Rated Load Up Noise | 78 db |
| Source Tube size | G3/4 mm |
| Cable Number | 2 |
| Control Method | Pendant control |
| Payment term | TT |
| Package | Standard Export Package |
As the name suggests, the fixed type air hoist is mainly used to lift and carry heavy objects in a specific position. It is driven by compressed air and adopts an upper hook design. Usually, it is used in combination with overhead cranes, jib cranes, and gantry cranes. Fixed pneumatic hoists are suitable for occasions where repetitive operations need to be carried out at specific heights and fixed positions. For example, in the petroleum, chemical, coal mining, textile, warehousing, and other industries, this equipment is commonly used for lifting operations in a fixed position. Moreover, it has a simple design, easy operation, and low maintenance cost, and is suitable for long-term use in a fixed location. If you have an interest in our hoist, please feel free to get in touch with us.
The main difference between fixed and running pneumatic hoists lies in their design and functionality. The specific details are as below.
Fixed pneumatic hoist: It adopts an upper hook design and is equipped with a handle featuring two buttons. It is usually fixed at a specific location and can also be used in conjunction with non-powered tracks. Its primary function is to lift heavy objects up and down, suitable for repetitive operations at a fixed height and position.
Running pneumatic hoist: It is equipped with a pneumatic trolley and can be moved forward, backward, left, and right by a handle with four buttons. It can be installed on I-beams or cantilever crane tracks, capable of lifting vertically and moving horizontally. It is suitable for scenarios where heavy objects need to be moved and lifted over a large area.
Fixed pneumatic hoist: It is suitable for repetitive operations at a fixed height and position, such as in chemical plants, warehouses, textile factories, and other places where heavy objects need to be lifted at a fixed location.
Running pneumatic hoist: It is suitable for scenarios where heavy objects need to be moved and lifted over a large area, such as in industrial production, logistics and warehousing, and other places where frequent mobile operations are required.
When it comes to buying pneumatic hoists, my clients all search for them on Google and select a supplier to order from the search result pages. However, a well-known hoist manufacturer is a suitable choice for you when buying. As we all know, a manufacturer and a trader have some differences in hoist quality, price, service, etc. The manufacturer can provide you with a hoist of the best quality, competitive price, and with good before and after-sales service. You should choose a stable supplier or manufacturer when you purchasing. And price comparison is also important for you. Most importantly, you should send your requirements to the suppliers, such as lifting speed, lifting weight, and lifting height, etc. That is because different types of fixed-type air hoists have different prices. Dejun is an experienced and skilled pneumatic hoist manufacturer in China. At Dejun, we have our factory. Moreover, at our factory, we have 3 pneumatic hoist manufacturing lines to meet your order needs. In addition, we have highly skilled technical engineers to design and research hoists to meet the market needs. You are welcome to visit our factory!
As a pneumatic hoist manufacturer, we are devoted to providing high quality hoists for our customers. Apart from the fixed type pneumatic hoist, we also can supply trolley type air hoists with you. Any needs, please contact us at any time!
